G-2108

Image Gallery

  • header

Product Description

  • Printing method : Direct thermal / Thermal transfer
  • Printing resolution: 203dpi (8 dots/mm)
  • Printing speed: Max. 4ips (101.6mm/s)
  • Printing width: Max. 4.25" (108mm)
  • Printing length: 0.22" – 40" @ (6mm – 1016mm)
  • Memory: 4MB SDRAM, 2MB Flash ROM
  • Processor: 32 bit embedded ARM CPU
  • Media Sensing: Adjustable position sensor for die-cut label & tags; Reflective sensor for use with per-printed eye-marks; Automatic sensing for continuous forms.
  • Media: Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal paper. Width: 25mm – 110mm Supply roll : OD – 6" (152mm) ; ID – 1" (25.4mm)
  • Ribbon: Wax, Wax/Resin, Resin. Ribbon roll: OD – 3" (76.2mm) ; ID – 1" (25.4mm) Max. Width: 110mm; Max. Length : 360M
  • Communication Interface: RS-232 serial; Centronics Parallel; USB (optional)
  • Display Interface: LED indicator x 3
  • Fonts: Postek internal printing fonts All windows fonts
  • Barcode: Code 39, Code 128, UCC/EAN-128, EAN-13/8, UPC-A/E 2&5 add on, Code 93, Interleave 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Codabar, China Post and PDF 41.7”
  • Graphics: BMP, PCX, JPG and etc
  • Software: Postek printer language Windows driver ( Win95/98/ME/XP/NT/2000) PosLabel printing software with ODBC Database function
  • Physical: W 256 x D 329 x H 200 mm 3.5 Kgs
  • Power rating: 24VDC, 2.5A
  • Power adaptor: Input 100-240 VAC, 50-60 Hz Output 24VDC, 2.5A
  • Operation Environment: Temperature : 40˚ F – 100˚ F ( 0˚ C – 40˚ C) Relative humidity: 5% - 85% non condensing
  • Accessories: Label Cutter Label Dispenser kit Internal 100/10M Ethernet Interface Card
